输入阻抗Input Impedance                                        50(Ω)

驻波比系数 VSWR                                                      <1.5

增益Gain                                                                  15(dBi)

半功率波束（3dB）HPBW                                          65°H-Plane        13°E-Plane

前后比F/B                                                                 >25(dB)

功率容量 Maximum Power                                        500(W)

极化方式Polarization                                                垂直极化Vertical Polarization

交调 PIN                                                                  <-107(dBm)

接口Connector Protection                                       7/16或N-K

闪电保护Light Protection                                         直接接地Direct Ground

抗风Wind Velocity                                                   200(km/h)

高/宽/厚Height/Wide/Depth                                    785/165/55(mm)

重量Weight                                                             2.8(kg)

抱杆直径Hold Pole Diameter                                   50-110(mm )
