型号Model                                                                KTWTF-11180-2.6V

频率范围Frequency Range                                         2500-2700(MHz)

输入阻抗Input Inpedance                                          50(Ω)

驻波比系数VSWR                                                        <1.5

增益Gain                                                                   11(dBi)

半功率波束(3dB)HPBW                                               8°E-plane    180°H-plane

前后比F/B                                                                   >12(dB)

功率容量Maximum Power                                           500(W)

极化方式Polarization                                                  垂直极化 Vertical Polarization

接口Connector Type                                                  N-K

闪电保护Lighting Protection                                       直接接地 Direct Ground

抗风Wind Velocity                                                      200(km/h)

长度Length                                                                900(mm)

重量Weight                                                                5.5(Kg)
